This plate must be worn on top of a Level IIIA vest in order to achieve Level III performance
Mission-Built for Patrol & Tactical Teams
When seconds count, patrol officers need rifle-rated protection that won’t slow them down. The Nexus 8x10 ICW Plate slips into the trauma pocket of our NIJ-certified Level IIIA uniform and concealment vests and instantly upgrades your cardiac-box coverage to Level III+/RF1. Engineered specifically for law enforcement, it delivers the stopping power you demand with the weight savings you need.
Equip officers with the Nexus 8x10 ICW Plate and stand ready for today’s rifle threats without sacrificing mobility or budget. Request a quote for department-wide deployment.
Key Advantages for Police & First-Responders
-
Field-Tested RF1 Stopping Power
-
Defeats common rifle threats (5.56 M193 @ 3,250 fps, 7.62×39 MSC @ 2,400 fps, 7.62 M80 @ 2,780 fps) when worn ICW with our certified IIIA soft armor.
-
-
100 % Larger Coverage vs. 5×8 Trauma Plates
-
Full 8 × 10 in cardiac-box footprint shields vital organs during active-shooter or barricade calls.
-
-
Ultra-Light, All-Day Wear
-
Advanced UHMWPE core weighs just 1.8 lb and measures < ¾" thick; you’ll barely notice it on patrol, in CQB training, or during extended perimeter duty.
-
-
Multi-Curve, Shooter’s Cut
-
Ergonomic geometry hugs the torso for an unrestricted draw, low-ready, or carbine shoulder weld.
-
-
Rugged Cordura® Skin
-
Resists duty grime, sweat, and abrasion; easy to wipe down between shifts.
-
-
Stab & Slash Resistant
-
Extra peace of mind during high-risk transports and cell extractions.
-
-
7-Year Warranty & NIJ-Verified Lab Testing
-
Full documentation is available for command staff and procurement teams.
Spec Details Size 8 × 10 in (20.3 × 25.4 cm) Thickness 16 mm (< ¾ in) Weight 1.8 lb (0.82 kg) Material UHMWPE core, 500D Cordura® wrap Curve / Cut Multi-curve, Shooter’s Rating NIJ Level III+/RF1 (ICW) Compatibility Fits Hybrid Concealment Vest & most IIIA duty carriers -
Rating & Testing
NIJ STANDARD TESTED ROUNDS
| Round | Velocity (ft/s) |
|---|---|
| 7.62×51mm M80 FMJ | ~2,780 ft/s |
| 7.62×39mm MSC (Type 56 Steel Jacketed Core) | ~2,400 ft/s |
| 5.56×45mm M193 FMJ | ~3,250 ft/s |
In addition to stopping penetration, the armor must limit backface deformation to 44mm to reduce blunt force trauma.
To learn more about the NIJ body armor standards, read our Understanding Body Armor Ratings article.
OFFICIAL TEST REPORT
Want to see the full test report? Download the test document below:
*Note: In the penetration column, "P" stands for partial penetration, meaning the bullet was captured by the armor and did not fully pass through. This is a successful result. A failure would be marked as "C" or "CP" for complete penetration, indicating the bullet fully passed through the armor.
View Full Test Report (PDF)Why Agencies Choose Nexus ICW
-
Rapid Rifle Upgrade: Issue plates at roll-call; officers' vests are already equipped to accept the upgrade.
-
Budget-Friendly Procurement: Lower cost and weight than stand-alone rifle plates, yet meets modern patrol-rifle threats.
-
Minimal Training Impact: No changes to qual course; plate rides in the same pocket as your current trauma insert.
Bulk & Agency Quotes: Use the “Add to Quote” button to start an initial quote. Quantity discounts, Net 30 terms, and GSA options available.
